EG4 WallMount Indoor 14.3kWh 280Ah Lithium Battery | 51.2V | Heated | UL1973 UL9540A
Questions about this product
Questions about this product
What is the EG4 WallMount Indoor 14.3 kWh battery?
A 51.2 V, 280 Ah LiFePO4 wall-mount battery with LCD, integrated self-heating, dual fire arrestors, and 600 A internal busbars. Rated for over 8,000 cycles at 80% DoD, 10-year warranty, UL 1973 and UL 9540A.
What are the charge and discharge limits?
Max continuous charge and discharge are 140 A. EG4 recommends 60–140 A in normal use. The BMS trips around 200 A, so design wiring and protection accordingly.
What is the operating temperature range?
Charge 0 to 50°C. Discharge −20 to 55°C. Storage 0 to 45°C. Indoor rating is IP20.
Does it support closed-loop communication with my inverter?
Yes. Selectable CAN or RS485 with EG4 inverters and options for Schneider, Sol-Ark, Victron, Growatt, Megarevo, Luxpower, and Deye. Protocols are set from the battery’s LCD.
How many can I parallel and do I need external busbars?
Using the built-in 600 A busbars, up to 3 batteries with one inverter, 4 with two inverters, or 5 with three inverters. Larger systems require external busbars and fusing sized at 200 A per battery. Do not series connect these batteries.
Delivery and shipping
Delivery and shipping
Orders are typically processed within 1 to 2 business days from the time of purchase, excluding holidays and weekends.
Shipping times and cost will vary depending on the product and your location.
On average:
Ontario and Quebec: 2 to 5 business days
Western Canada: 4 to 7 business days
Atlantic provinces: 4 to 8 business days
Northern or remote areas: Contact us to confirm
System Load Calculator
* Usage / consumption may vary.
EG4 WallMount Indoor 14.3kWh 280Ah Lithium Battery | 51.2V | Heated | UL1973 UL9540A
The EG4 WallMount Indoor 14.3kWh 280Ah Lithium Battery is a high-capacity, low-voltage residential energy storage solution engineered for serious whole-home backup and load shifting. Using lithium iron phosphate (LiFePO4) cells and an intelligent Battery Management System, it delivers reliable, safe power with real-time monitoring of cell voltage, pack voltage, current and temperature.
Designed specifically for indoor wall-mount applications, this unit combines a slim profile with integrated 600A busbars, multiple connection points and selectable closed-loop communications with popular inverter brands. An onboard LCD touch screen makes configuration and diagnostics simple, while dual onboard fire arrestors and an integrated self-heating feature provide additional layers of safety and cold-weather performance.
With over 8,000 cycles at 80 percent depth of discharge and a design life of more than 15 years, this 14.3kWh battery is built for long-term, high-demand residential storage systems that need both capacity and resilience.
Key Features
Application: Indoor low-voltage residential energy storage
Chemistry: Lithium iron phosphate (LiFePO4) for high safety and stability
Total Energy Capacity: 14.3kWh
Nominal Voltage: 51.2V
Capacity: 280Ah
Battery Management System: Intelligent BMS with real-time monitoring of cell voltage, module voltage, current and temperature
Balancing: Passive cell balancing and advanced battery control for optimal performance
Closed-Loop Communications: Selectable RS485/CAN integration with EG4, Schneider, Sol-Ark, Victron, Growatt, Megarevo, Luxpower and Deye inverters
On-Board LCD Touch Screen: Easy access to status, configuration and monitoring
Integrated Busbars: 600A internal busbars with four positive and four negative terminals
Parallel-Friendly Design: Multiple terminals reduce or eliminate external busbars when paralleling batteries or inverters
Emergency Stop Capability: Optional ESS disconnect can shut down all batteries and compatible inverters from a single point
Self-Heating Feature: Internal heating maintains proper cell temperature in cold environments
Dual On-Board Fire Arrestors: Added protection against thermal runaway and high-risk conditions
Ingress Protection: IP20 rated for indoor environments
